EXCTG Registration when the Copy Operation is Performed in the Forward Direction
Table 72 (page 237) through Table 74 (page 237) show the registration status when the current copy
operation is performed in the forward direction:
Table 72 When Registering Both EXCTG(Forward) and EXCTG(Reverse)
EXCTG registration flag Storage system status
of the copy pair
2
Copy pair status
1
EXCTG registration
status
Nothing is displayed SIMPLEX SIMPLEX Not registered yet
inactive(0,0) -
N/A(N/A,0)
PENDING/DUPLEX PENDING
active(0,1) - N/A(N/A,1) PENDING/DUPLEX PENDING During registration
active(1,1) - N/A(N/A,1) PENDING PENDING Registered
DUPLEX DUPLEX
Table 73 When Registering EXCTG(Forward) Only
EXCTG registration flag Storage system status
of the copy pair
2
Copy pair status
1
EXCTG registration
status
Nothing is displayed SIMPLEX SIMPLEX Not registered yet
inactive(0,0) -
N/A(N/A,0)
PENDING/DUPLEX PENDING
active(0,1) - N/A(N/A,0) PENDING/DUPLEX PENDING During registration
active(1,1) - N/A(N/A,0) PENDING PENDING Registered
DUPLEX DUPLEX
Table 74 When Registering EXCTG(Reverse) Only
EXCTG registration flag Storage system status
of the copy pair
2
Copy pair status
1
EXCTG registration
status
Nothing is displayed SIMPLEX SIMPLEX Not registered yet
inactive(0,0) -
N/A(N/A,0)
PENDING PENDING
DUPLEX DUPLEX
inactive(0,0) -
N/A(N/A,1)
PENDING PENDING Registered
DUPLEX DUPLEX
EXCTG Registration when the Copy Operation is Performed in the Reverse Direction
Table 75 (page 237) through Table 77 (page 238) show the registration status when a copy operation
is performed in the reverse direction:
Table 75 When Registering both EXCTG(Forward) and EXCTG(Reverse)
EXCTG registration flag Storage system status
of the copy pair
2
Copy pair status
1
EXCTG registration
status
Nothing is displayed SIMPLEX SIMPLEX Not registered yet
N/A(N/A,0) -
inactive(0,0)
PENDING/DUPLEX PENDING
N/A(N/A,1) - active(0,1) PENDING/DUPLEX PENDING During registration
