NOTE: For an XP10000 Disk Array, the MIX boards do not have MP4, 5, and 6 defined. So,
when these metrics are chosen, the utilization is shown as zero.
The Utilization metric is available for the DKAs that are associated with the concatenated RAID
groups. All the associated DKA pairs are displayed individually in the Resource list box on the
Charts screen.
TIP: For CHIPs that are not installed, the MP utilization shows zero.
Related Topics
•
“Front-end navigation path” (page 241)
•
“Back-end navigation path” (page 247)
•
“MP Blades navigation path” (page 245)
•
“Pools navigation path” (page 250)
•
“Snapshot Pool navigation path” (page 254)
•
“Replication Volumes navigation path” (page 256)
•
“LUSE navigation path” (page 258)
•
“Host Groups navigation path” (page 259)
•
“Ext-RG(s) navigation path” (page 264)
•
“Drive types navigation path” (page 265)
•
“Custom groups navigation path” (page 267)
MP Blades navigation path
IMPORTANT: This section is applicable only for the P9000 disk arrays.
The MP Blades main category comprises the individual MP blades for a P9000 disk array. Each
MP blade is identified by the cluster # and the blade location, and further displays the list of
processors. Following is the component selection path: MP Blades > Individual MP Blade (ID, cluster
#, blade location) > Processors (component type) > Individual processor IDs.
•
MP Blades > Individual MP Blade
•
Individual MP Blade > Processors (component type) > Individual processor IDs
The number of components associated with an MP blade is displayed beside it. For example:
•
MP Blade (2)
•
Processors (4)
Plotting charts 245
