HP XP P9000 Performance Advisor Software User Manual
Page 189

For P9000 disk arrays
For XP disk arrays
Individual CHIP/CHA data
Yes
Yes
The maximum and minimum I/Os on
individual ports
Yes
Yes
The maximum, minimum, and average
throughput of data in MB/s on individual
ports
Example:
The following image displays the CHA-1EU performance data for 53036, which belongs to the
P9500 Disk Array type.
The individual performance data for CHA-1EU includes the following:
•
Summary:
Fibre protocol is used
◦
◦
Eight ports are associated with CHA-1EU
◦
Port Activity Avg shows average I/Os as 10409.17, which is an average of the overall
average I/Os on all the eight ports. It also displays the average MB/s as 81.33, which
is the an average of the overall average MB/s on all the eight ports.
•
Port Details:
CL1A, CL5A, CL3A, and CL7A are the ports for CHA-1EU
◦
◦
Maximum and minimum I/Os
◦
Maximum, minimum, and average throughput of data in MB/s
For example, the Max I/Os and Min I/Os for CL1A are 17290.00 and 5998.00
Related Topics
•
“Viewing performance summary” (page 177)
•
“Viewing ACP/DKA data” (page 190)
•
“Viewing MP blade utilization for P9000 disk arrays” (page 193)
•
“Viewing Smart and ThP pools data for P9000 disk arrays” (page 197)
•
“Utilization Summary” (page 183)
•
“10 busiest LDEVs/Ports” (page 208)
•
“10 busiest LDEVs/RAID groups” (page 209)
•
•
“Viewing LDEV data” (page 216)
