Install Appliance in Rack
1. Attach the node rails to the node.
Figure 20 Attaching a node rail to the node
.
WARNING!
The node is very heavy, 44.5 kg (98 lb) full. To reduce the risk of personal injury or damage
to the equipment:
• Remove the hot-plug power supplies to reduce the weight of the node before lifting it.
Do not remove any other hardware.
• Observe local occupational health and safety requirements and guidelines for material
handling.
• At least two people are required to lift and rack mount the node.
2. Remove the node power supplies. See Power Supply .
3. Pull the inner slide rail forward from each rack rail assembly until it locks into place.
