HP StorageWorks 6000 Virtual Library System - Manual (Page 236)

Description Item
PCIe slot 1 5
PCIe slot 2 6
NMI jumper 7
iLO 2 diagnostic LEDs 8
System maintenance switch 9
Internal USB connector
1 10
System battery 11
PCI riser cage connector 12
Fan 4 connector 13
Fan 2 connector 14
Fan 3 connector 15
Fan 1 connector 16
FBDIMM slots (1–8) 17
Multibay interface connector 18
Processor socket 1 19
Processor socket 2 20
1
The lower USB connection is unavailable.
FBDIMM Slots
FBDIMM slots are numbered sequentially (1 through 8) and the paired banks are identified by the
letters A, B, C, and D.
Component Identification 236
