3. With the node fully seated in the rack, tighten the thumbscrews just until the node bezel is secured
to the rack.
Installing the VLS6600 Node into a Rack
NOTE:
If you are installing the node into a telco rack, order the appropriate option kit at the RackSolutions.com
web site:
http://www.racksolutions.com/hp . Follow the instructions on the web site to install the rack
brackets.
NOTE:
Allow enough rack space above and/or below the node to mount the disk arrays. A disk array
requires a vertical rack space of 2U (equivalent to 89 mm, or 3.5 inches).
To install a VLS6600 node into the rack involves three main tasks:
1. Install Rails in the Rack
2. Attach Rails to the VLS6600 Node (appliance)
3. Install Appliance in the Rack
Install Rails in the Rack
To install the rails in the rack:
1. Locate the appropriate rail kit—part number 365517-B21.
Hardware Installation 46
