Description

Item

Internal USB connector

15

System battery

16

PCI riser board connector 2

17

PCI riser board connector 1

18

Accessing the VLS6200 HP Systems Insight Display

To eject the HP Systems Insight Display:

1.

Press and release the display.

2.

Extend the display from the chassis.

The display can be rotated up to 90 degrees.

HP Systems Insight Display and LEDs

The display provides status for all internal LEDs and enables diagnosis with the access panel installed.

To view the LEDs, access the HP Systems Insight Display.

Component Identification

226
