Status Description Item
• Green = Auxiliary power is applied.
• Off = Auxiliary power is not applied.
Standby power good 11
• Amber = One fan in this module has failed.
• Red = Multiple fans in this module have
failed.
• Off = All fans in this module are operating
normally.
Power supply fan module failure 12
Refer to the HP Remote Lights-Out Edition II User
Guide.
System diagnostic 13
• Amber = Failover has occurred. Online spare
memory is in use.
• Green = Online spare memory is enabled,
but not in use.
• Off = Online spare memory is disabled.
Online spare memory 14
• Amber = PCI riser assembly is not seated.
• Off = PCI riser assembly is seated.
Riser interlock 15
Node LEDs and Internal Health LED Combinations
When the internal health LED on the front panel of the node illuminates either amber or red, the node
is experiencing a health event. Combinations of illuminated system board LEDs and the internal health
LED indicate node status.
Status
Internal Health
LED Color System board LED
and color
One or more of the following conditions may exist:
• Processor in socket X has failed.
• Processor in socket X failed over to the offline spare.
• Processor X is not installed in the socket.
• Processor X is unsupported.
• ROM detects a failed processor during POST.
Red
Processor failure,
socket X (Amber)
Processor in socket X is in a pre-failure condition. Amber
Processor types are mismatched. Red
Processor failure,
both sockets (Am-
ber)
PPM has failed. Red PPM failure (Amber)
• DIMM in slot X has failed.
• DIMM in slot X is an unsupported type, and no valid memory
exists in another bank. Red
DIMM failure, slot X
(Amber)
