Figure 3 VLS6800 disk array rack mounting order

.

Description

Item

Disk array 15

1

Disk array 14

2

Disk array 13

3

Disk array 12

4

Disk array 11

5

Disk array 10

6

Disk array 9

7

Disk array 8

8
