3. Click View. The View button is enabled only when you select LDEV records in the Custom
Groups table.
The View Custom Group Details screen appears providing the list of LDEVs added to the
selected custom group. The following table describes the column headings in the Group Details
screen.
Table 7 Group Details screen
Description Screen elements
Displays
the IDs of the selected XP and XP7 disk arrays.
DKC
Displays the type of the selected XP disk array (for
example, XP24000, XP20000, XP12000, or P9500). Array Type
Displays the IDs for the selected hosts. Host ID
Displays the XP disk array device file names that are
pointing to the selected host. Device File
If an XP disk array is connected to a host that has a
host agent installed for HP-UX 11i v3 operating system,
the DSF is displayed in a new format. A legacy DSF is
displayed in parenthesis next to the new format.
Displays the identification numbers of the selected ports. Port
The
port type, such as Fibre or FCoE (applicable only
for
XP7 disk arrays).
Port Type
Displays the SLPR groups that belong to the selected
ACP pair. SLPR
NOTE: SLPR
does not exist in the P9500/XP7 and
P9500/XP7
disk arrays. So, a – is displayed in this
column
for the XP7 disk arrays.
For an XP disk array, the CLPR column displays the CLPRs
for an SLPR that belongs to the selected ACP pair. CLPR
For an P9500/XP7 disk array, the CLPR column displays
the CLPRs that belong to the selected ACP pair.
Displays the identification numbers of the selected logical
devices that belong to a particular continuous access
journal group. LDEV
Displays one of the following for a selected LDEV: LUSE Status
• Blank field = Not a LUSE
•
M = A LUSE master
• C = A LUSE component port
NOTE: LUSE
is not supported for XP7 arrays
Displays the LDEV ID of the LUSE master, if the selected
LDEV is a LUSE component. If the LDEV is not a LUSE
component, this field is blank. LUSE Master
Displays the following options to indicate whether or
not the selected LDEV is an Ext-LUN (Ext-LDEV): Ext-Lun
•
- (hyphen) = Normal LUN
• E = Ext-Lun
•
P = Ext-Lun provider (the selected LDEV is used as an
Ext-LUN
for another XP or XP7 disk array)
Managing custom groups 87
