D Appendix D
Array mapping
“XP12000” (page 384) lists the ACP and CHIP pairs for XP12000 type array.
Table 35 XP12000
Slot ID Pair ID Slot name
ACP A = 0; M = 4 ACP Pair 1 A, M
ACP B = 1; N = 5 ACP Pair 2 B, N
ACP L = 2; X = 6 ACP Pair 3 L, X
ACP K = 3; W = 7 ACP Pair 4 K, W
CHIP E = 0; Q = 4 CHIP Pair 1 E, Q
CHIP F = 1; R = 5 CHIP Pair 2 F, R
CHIP G = 2; T = 6 CHIP Pair 3 G, T
CHIP H = 3; U = 7 CHIP Pair 4 H, U
CHIP A = 8; M = 12 CHIP Pair 5 A, M
CHIP B = 9; N = 13 CHIP Pair 6 B, N
CHIP L = 10; X = 14 CHIP Pair 7 L, X
CHIP K = 11; W = 15 CHIP Pair 8 K, W
“XP10000 ” (page 384) lists the ACP and CHIP pairs for the XP10000 type arrays.
Table 36 XP10000
Slot ID Pair ID Slot name
ACP MIX-A = 0; MIX-F = 4 ACP Pair 1 MIX-A, MIX-F
CHIP MIX-A = 8; MIX-F = 12 CHIP Pair 1 MIX-A, MIX-F
CHIP B = 9; E = 13 CHIP Pair 2 B,E
“XP24000” (page 384) lists the ACP and CHIP pairs for an XP24000 type array.
Table 37 XP24000
Slot ID Pair ID Slot name
ACP AU=0; MU=8 ACP Pair 1 AU, MU
ACP BU=2; NU=10 ACP Pair 2 BU, NU
ACP AL=1; ML=9 ACP Pair 3 AL, ML
ACP BL=3; NL=11 ACP Pair 4 BL, NL
ACP LU=4; XU=12 ACP Pair 5 LU, XU
ACP KU=6; WU=14 ACP Pair 6 KU, WU
ACP LL=5; XL=13 ACP Pair 7 LL, XL
ACP KL=7; WL=15 ACP Pair 8 KL, WL
