The applicable metrics are displayed in the Available Metrics Choose Metric Category list. Select
the metrics at the component type or the individual component levels, or both and view the related
performance graphs in the Chart Work Area. For a description of these metrics, see
“Metric
Category, metrics, and descriptions” (page 386) .
The following table provides the default set of metric categories that are displayed in the Available
Metrics Choose Metric Category list for the XP disk array.
Most used default metric category Snapshot Pool category for XP disk array
Frontend IO Metrics Snapshot pool ID
Utilization Metrics RGs
Frontend IO Metrics LDEVs
Frontend IO Metrics VVols
Frontend IO Metrics Host Group
Frontend IO Metrics P-Vol
Frontend IO Metrics S-Vol
Related Topics
•
“Front-end navigation path” (page 239)
•
“Cache navigation path” (page 241)
•
“MP Blades navigation path” (page 243)
•
“Back-end navigation path” (page 244)
•
“Replication Volumes navigation path” (page 253)
•
“Pools navigation path” (page 247)
•
“LUSE navigation path” (page 255)
•
“Host Groups navigation path” (page 257)
•
“Ext-RG(s) navigation path” (page 261)
•
“Drive types navigation path” (page 262)
•
“Custom groups navigation path” (page 265)
Replication Volumes navigation path
The Replication Volumes main category comprises of the business copy and the continuous access
volumes. They are the main component types that further expand to display the associated
components. Following is the component selection path:
•
Replication Volumes > Business Copy Volumes (component type) > Individual LDEVs used as
business copy volumes
•
Replication Volumes > Continuous Access Volumes (component type) > Individual Journal Pool
IDs > LDEVs > Individual LDEVs assigned to a journal pool
The number of components associated with a component type is displayed beside it. For example:
•
Business Copy Volumes (104)
•
Continuous Access Volumes (4)
•
LDEVs (1)
Plotting charts 253
