NOTE:

The LDEVs, journal groups, or the E-LUNs are referred as consumers on the Dashboard

screen.

By default, the consumers are sorted in a descending order and displayed in the Component
Information section. The consumers with quicker average read and write response time or a high
average MP blade utilization are displayed first, followed by those with higher response time and
low average utilization values.

You can specify the number of consumers that must be displayed in the Component Information
section of the Dashboard screen. The maximum acceptable number is 50 and the minimum
acceptable number is 0. By default, 20 consumers are displayed at a time in the Component
Information section when you click a port, RAID group, or an MP blade in the Statistics section. If
there are less than 20 consumers, all of them are displayed in the Component Information section.

To specify the consumer settings:
1.

Go to the Component Settings section on the Threshold Setting screen.

From the Maximum Components list, select the maximum number of consumers you want to
view in the Component Information section of the Dashboard screen.

Select Ascending or Descending as the Sort by Average Response Time.

Click Save to update the consumer settings.

The maximum X busiest consumers appear in the Component Information section on the Dashboard
screen. For more information, see

“Dashboard busiest consumers” (page 112)
