Pro-EC44 2-Loop Graphical Profile Controller & Recorder

Pro-EC44 Product Manual - 59540-1 October 2013

Page 193

Hold

0 = Operator Null (0)

Wait for the operator to release the hold

1 = Time of
day

Start Time

Wait until time of the day “B” in seconds since
midnight (recorder only).

2 = Digital
input

Null (0)

Wait for digital input signal

Loop

Number of
times to
repeat 1 to
9999

Segment
number

Loop to the specified segment number “B”
from this point. Repeat this “A” times.

Note: Only segments below the current
segment can be entered. Two "loop-backs"
must not cross each other.

Join

Null (0)

Profile
number

On completion of this profile jump run profile
“B”

End

0 = Control
off

Null (0)

Turn off all control outputs on the loop(s)
controlled by the profile. Doesn't affect loop 2
on single loop profiles.

1 = Maintain
profile
setpoint

Null (0)

Stay at the final setpoint of the profile

2 = Use
controller
setpoint

Null (0)

Use the active controller setpoint (e.g. Main or
Alternate as selected). This exits from Profiler
Mode back to Controller Mode.

Repeat Sequence Then End

0 = Outputs
off

Number of
times to
repeat
sequence

Repeat the profile sequence number “B” times,
then turn off the control outputs

1 = Maintain
profile
setpoint

Repeat the profile sequence number “B” times,
then hold the last profile setpoint.

2 = Use
controller
setpoint

Repeat the profile sequence number “B” times,
then use the active controller setpoint (e.g.
Main or Alternate as selected). This exits from
Profiler Mode back to Controller Mode.

The instrument replies to this message with an Edit Response Message.

Deleting All or Single Profiles

An individual profile can be deleted, or all profiles can be deleted with a single message.
Deleting a profile removes the header of the specified profile and any segments associated
with it. Delete all profiles wipes all profiles and segments from the instrument.

Delete Profiles - Request (to instrument)

Field Name

Data

Comments

Dec

Hex

Unit Address

A/R

A/R

The network address ID of the instrument.

Function Code

23

17

Requires the multi read/write function

Read Start Address High Byte

32

20

Read Start Address Low Byte

6

6

Read Quantity Of Registers High

0

0

Read Quantity Of Registers Low

1

1

Write Start Address High

32

20

Write Start Address Low

6

6

Write Quantity Of Registers High

0

0

Write Quantity Of Registers Low

02 or

01

02 or

01

Delete A Profile (DP) = 02dec / 0x02hex

Delete All Profiles (DA) = 01dec / 0x01hex
