Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-1 October 2013
Page 121
Input 2 Scale Point 7
Multi-Point Scaling Point 7
Dec
1142
17526 35052
RW
Percentage of the scaled input where multi-point scaling value 7
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
0476
4476
88EC
Input 2 Display Point 7
Multi-Point Scaling Display Value For Point 7
Dec
1143
17527 35054
RW
Value to display at multi-point scaling point 7
Valid between the scaled input lower & upper limits
Hex
0477
4477
88EE
Input 2 Scale Point 8
Multi-Point Scaling Point 8
Dec
1144
17528 35056
RW
Percentage of the scaled input where multi-point scaling value 8
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
0478
4478
88F0
Input 2 Display Point 8
Multi-Point Scaling Display Value For Point 8
Dec
1145
17529 35058
RW
Value to display at multi-point scaling point 8
Valid between the scaled input lower & upper limits
Hex
0479
4479
88F2
Input 2 Scale Point 9
Multi-Point Scaling Point 9
Dec
1146
17530 35060
RW
Percentage of the scaled input where multi-point scaling value 9
is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
047A
447A
88F4
Input 2 Display Point 9
Multi-Point Scaling Display Value For Point 9
Dec
1147
17531 35062
RW
Value to display at multi-point scaling point 9
Valid between the scaled input lower & upper limits
Hex
047B
447B
88F6
Input 2 Scale Point 10
Multi-Point Scaling Point 10
Dec
1148
17532 35064
RW
Percentage of the scaled input where multi-point scaling value
10 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
047C
447C
88F8
Input 2 Display Point 10
Multi-Point Scaling Display Value For Point 10
Dec
1149
17533 35066
RW
Value to display at multi-point scaling point 10
Valid between the scaled input lower & upper limits
Hex
047D
447D
88FA
Input 2 Scale Point 11
Multi-Point Scaling Point 11
Dec
1150
17534 35068
RW
Percentage of the scaled input where multi-point scaling value
11 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
047E
447E
88FC
Input 2 Display Point 11
Multi-Point Scaling Display Value For Point 11
Dec
1151
17535 35070
RW
Value to display at multi-point scaling point 11
Valid between the scaled input lower & upper limits
Hex
047F
447F
88FE
Input 2 Scale Point 12
Multi-Point Scaling Point 12
Dec
1152
17536 35072
RW
Percentage of the scaled input where multi-point scaling value
12 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
0480
4480
8900
Input 2 Display Point 12
Multi-Point Scaling Display Value For Point 12
Dec
1153
17537 35074
RW
Value to display at multi-point scaling point 12
Valid between the scaled input lower & upper limits
Hex
0481
4481
8902
Input 2 Scale Point 13
Multi-Point Scaling Point 13
Dec
1154
17538 35076
RW
Percentage of the scaled input where multi-point scaling value
13 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
0482
4482
8904
Input 2 Display Point 13
Multi-Point Scaling Display Value For Point 13
Dec
1155
17539 35078
RW
Value to display at multi-point scaling point 13
Valid between the scaled input lower & upper limits
Hex
0483
4483
8906
Input 2 Scale Point 14
Multi-Point Scaling Point 14
Dec
1156
17540 35080
RW
Percentage of the scaled input where multi-point scaling value
14 is applied.
0.1 to 100.0% *set to 100% ends scaling sequence at that point.
Hex
0484
4484
8908
