background image

Pro-EC44 2-Loop Graphical Profile Controller & Recorder

Pro-EC44 Product Manual - 59540-1 October 2013

Page 11

Sensor Placement (Thermocouple or RTD)

If a temperature probe is to be subjected to corrosive or abrasive conditions, it must be
protected by an appropriate thermowell.

Probes must be positioned to reflect the true process temperature:

1. In a liquid media - the most agitated area

2. In air - the best circulated area

CAUTION:

The placement of probes into pipe work some distance from the

heating vessel leads to transport delay, which results in poor control.

For a two wire RTD, a wire link should be used in place of the third wire (see the wiring
section for details). Two wire RTDs should only be used with lead lengths less than 3 metres.
Use of three wire RTDs is strongly recommended to reduce errors do to lead resistance.

Thermocouple Wire Identification

The different thermocouple types are identified by their wires colour, and where possible, the
outer insulation as well. There are several standards in use throughout the world, but most
regions now use the International IEC584-3 standard.

The table below shows the wire and sheath colours used for most
common thermocouple types. The format used in this table is:

THERMOCOUPLE WIRE COLOUR CHART

Type

International

IEC584-3

USA ANSI

MC 96.1

British

BS1843

French

NFC 42-324

German

DIN 43710

J

+

*

Black

Black

White

Black

Yellow

Black

Yellow

Black

Red

Blue

-

White

Red

Blue

Black

Blue

T

+

Brown

Brown

Blue

Blue

White

Blue

Yellow

Blue

Red

Brown

-

White

Red

Blue

Blue

Brown

K

+

Green

Green

Yellow

Yellow

Brown

Red

Yellow

Yellow

Red

Green

-

*

White

Red

Blue

Purple

Green

N

+

Pink

Pink

Orange

Orange

Orange

Orange

-

White

Red

Blue

B

+

Grey

Grey

Grey

Grey

Red

Grey

-

White

Red

Grey

R & S

+

Orange

Orange

Black

Green

White

Green

Yellow

Green

Red

White

-

White

Red

Blue

Green

White

C (W5)

+

White

White

-

Red

Note: * = Wire is magnetic

– a magnet can be used to assist with correctly

identifying the type and polarity of the conductors

+

Wire

Sheath

-

Wire
