Pro-EC44 2-Loop Graphical Profile Controller & Recorder

Pro-EC44 Product Manual - 59540-1 October 2013

Page 157

Loop 1 Gain Set 4 Breakpoint

Gain Scheduling PID Set 3 To 4 Switch Point

Dec

4371

20755 41510

RW

Value (SP or PV) gain scheduling switches from PID Set 3 To 4.

Value between Set 3 Breakpoint & Scaled Input 1 Upper Limit.

Hex

1113

5113

A226

Loop 1 Gain Set 5 Breakpoint

Gain Scheduling PID Set 4 To 5 Switch Point

Dec

4372

20756 41512

RW

Value (SP or PV) gain scheduling switches from PID Set 4 To 5.

Value between Set 4 Breakpoint & Scaled Input 1 Upper Limit.

Hex

1114

5114

A228

Loop 1 Cascade Mode

Value

Cascade Master/Slave Link Status

Dec

4393

20777 41554

RW

0

Cascade Closed

Hex

1129

5129

A252

1

Cascade Open

Loop 1 Ratio NO Constant

Ratio NO Constant For Atomizing Air

Dec

4387

20771 41542

RW

0 to 9999 atomizing air value,

Added to the x1 value in ratio mode (air flow is x1 + NO).

Hex

1123

5123

A246

Loop 1 Ratio Sfac Constant

Ratio Sfac Constant

Dec

4388

20772 41544

RW

Ratio control mode scaling factor. Adjustable from 0.010 to

99.999

Hex

1124

5124

A248

Loop 2 Control Parameters

Parameter Name & Register Address

Integer Int +1

Float

Access

Values

& Descriptions

Loop 2 Manual Control Select

Value

Selection

Dec

4408

20792 41584

RW

0

Automatic Mode

Hex

1138

5138

A270

1

Manual Mode

Loop 2 Control Enable Select

Value

Control Enable Selection

Dec

4409

20793 41586

RW

0

Disabled

Hex

1139

5139

A272

1

Enabled

Loop 2 Auto/Manual Access

Value

Operator Access To Auto/Manual Control

Dec

4494

20878 41756

RW

0

Off

Hex

118E

518E

A31C

1

On

Loop 2 Control Enable Access

Value

Operator Access To Control Enable/Disable

Dec

4495

20879 41758

RW

0

Off

Hex

118F

518F

A31E

1

On

Loop 2 Primary Cycle Time

Cycle Time For Primary Control Outputs

Dec

4303

20687 41374

RW

0.5 to 512.0 Seconds

Hex

10CF

50CF

A19E

Loop 2 Secondary Cycle Time

Cycle Time For Secondary Control Outputs

Dec

4304

20688 41376

RW

0.5 to 512.0 Seconds

Hex

10D0

50D0

A1A0

Loop 2 Control Selection

Value

Control Actuator Type Selection

Dec

4407

20791 41582

RW

0

Standard (Time Proportioned or Continuous PID)

Hex

1137

5137

A26E

1

VMD (3-Point Stepping for Valve Motor Drive)

Loop 2 Control type

Value

Primary Only or Primary & Secondary

Dec

4410

20794 41588

RW

0

Single (Primary Only Control)

Hex

113A

513A

A274

1

Dual Control (Primary & Secondary Control)
