Pro-EC44 2-Loop Graphical Profile Controller & Recorder
Pro-EC44 Product Manual - 59540-1 October 2013 Page 185
Contact Details 1 “For Service” Contact Details - Lines 1 to 7
Dec 400 16784 33568
RW
7 lines of user definable text - 25 ASCII characters per line which
can be read or written using Modbus functions 16 or 23.
Note: The number of ASCII characters transmitted per line
must be EVEN. If the text string you wish to send has an
odd number, place an additional space character at the end.
The space character is 20 hex.
Valid characters are 0 to 9, a to z, A to Z, plus Я ц ( ) - and _.
Example. To write “My Company Name” to line 1 send:
[ADDRESS], 16, 01, 90, 00, 08, 10, 4D, 79, 20, 43, 6F, 6D, 70,
61, 6E, 79, 20, 4E, 61, 6D, 65, 20, [CRC]
Hex 0190 4190 8320
Contact Details 2
Dec 401 16785 33570
RW
Hex 0191 4191 8322
Contact Details 3
Dec 402 16786 33572
RW
Hex 0192 4192 8324
Contact Details 4
Dec 403 16787 33574
RW
Hex 0193 4193 8326
Contact Details 5
Dec 404 16788 33576
RW
Hex 0194 4194 8328
Contact Details 6
Dec 405 16789 33578
RW
Hex 0195 4195 832A
Contact Details 7
Dec 406 16790 33580
RW
Hex 0196 4196 832C
Profiler Control & Status Parameters
Parameter Name & Register Address
Integer Int +1 Float Access Values & Descriptions
Active Profiler Active Profiler Number
Dec 8243 24627 49254
RW Currently selected profile number (0 to 63)
Hex 2033 6033 C066
Active Segment Active Segment Number
Dec 8244 24628 49256
RO The active segment number (1 to 255) of the selected profile.
Hex 2034 6034 C068
Profiler Control Commands Value Profiler Command
Dec 8245 24629 49258
RW
0 Do nothing
Hex 2035 6035 C06A 1 Run the currently selected profile
Note: The Profiler Control Commands
must be followed by a Profiler Control
Confirmation Action command,
otherwise the command will not be
implemented.
2 Hold the currently running profile
3 Abort the currently running profile
4 Jump to the next segment
5 Release the hold
6 Exit profiler, return to controller mode
8 Select a profile to be run but not start it
Profiler Control Confirmation Action Value Implement Profiler Command
Dec 8257 24641 49282
RW
0 Do not Implement Command
Hex 2041 6041 C082 1 Implement previous Profiler Command
Enable Edit While Running Value Operator Editing of Current Running Profile
Dec 8262 24646 49292
RW
0 Editing of running profile forbidden
Hex 2046 6046 C08C 1 Editing of running profile via Keypad allowed
