Pro-EC44 2-Loop Graphical Profile Controller & Recorder

Pro-EC44 Product Manual - 59540-1 October 2013

Page 98

Uploading Data

Recordings can be transferred to a memory stick using the USB Port (See page 96). They
can also be uploaded directly to the PC software

via the configuration port or RS485/Ethernet

communications if fitted.

The data is stored in Comma Separated format
(.csv) which can be opened and analysed with the
optional PC software or opened directly into a
spreadsheet. Many third party software programs
can also import data in the .csv format.

The file contains a header identifying the source
instruments serial number, the date of the file
upload and descriptions of the data columns.

The data columns seen depends on the data
selected to record, but will always include the date
and time of each sample. The date format follows
the instrument date format selection. Date(en) is
dd/mm/yyyy, and Date (us) is mm/dd/yyyy.

Note: Analysis with the PC software is limited to 8 analogue channels, so only
the first 8 will be displayed. The number of recorded alarms & events is not
limited.

Additional Features & Benefits from the Recorder

The real time clock (RTC) included with the data recorder also expands the profiling
capabilities (see Profiler on page 87)

and allows a “calibration due” reminder to be shown at

a specified date (see the Input Configuration sub-menu on page 46).
