5.8.2 Viewing temperature information
To view the temperature of the Main Station:
2. In Menu mode [ ], select Diagnostics and then Hardware.
3. From the third menu (third display screen), select one of the following temperature sensors:
• Sensor 1
• Sensor 2
• Sensor 3
The fourth menu (fourth display screen) displays the temperature, for example:
+30°C
Environmental note:
The recommended operating temperature range for the HelixNet
HMS-4X Main Station is 0 - +50°C. The storage temperature range for the Main Station is
-30 - +70°C.
Single fan on if any sensor > 60°C.
Double fan on if any sensor > 65°C.
Double fan off if < 55°C / single fan off if < 50°C.
For more environmental information, see 3 Installing HelixNet Partyline.
5.8.3 Viewing powerline information and status
There are two digital partylines (Line 1 and Line 2) on the HMS-4X Main Station. Line 1 and Line 2 are
also referred to as powerlines.
Each line can support up to 10 HBP-2X beltpacks.
Note:
See also
F G
and
I
in Table 4: Key to HMS-4X Main Station front panel diagram.
To view line information and status:
1. In Menu mode [ ], select Diagnostics and then Powerlines.
2. From the third menu (third display screen), select one of the following:
• Powerline 1
Note:
Refers to Line 1.
• Powerline 2
Note:
Refers to Line 2.
69 HelixNet Partyline User Guide
