ISM 824 Integration Scaling Multiswitcher • Operation and Setup
Output Config submenu
Within this submenu, the resolution, the refresh rate, the output signal type, and
the sync polarity can be selected and adjusted.
1
.
From the Input Setup submenu press Menu.
2
.
Press Next to bring up the Resolution submenu. In this submenu, the
resolution and refresh rate can be adjusted.
Rotate the left front panel encoder (
[
) to adjust the resolution value, and
rotate the right encoder (
{
) to adjust the refresh rate.
N
There are 58 output resolutions (see table) to choose from (640 x 480 at 50 Hz
through 1080p at 60 Hz). The refresh rate is based on the resolution selected.
Resolution
24 Hz
25 Hz
30 Hz
50 Hz
60 Hz
72 Hz
75 Hz
640x480
X
X
X
800x600
X
X
X
852x480
X
X
X
1024x768
X
X
X
1024x852
X
X
X
1024x1024
X
X
X
1280x768
X
X
X
1280x1024
X
X
X
1360x765
X
X
X
1365x768
X
X
X
1366x768
X
X
X
1365x1024
X
X
X
1400x1050
X
X
1600x1200
X
X
480p
X
576p
X
720p
X
X
1080i
X
X
1080p
X
X
X
X
X
1280x800
X
X
1440x900
X
X
1680x1050
X
1920x1200
X
1080p Sharp
X
Figure 3-50 — ISM DVI output resolution/refresh rate table
3
.
Press Next to return to the upper level Output Config menu.
4
.
Press Menu to go to the next submenu (User Presets).
