10.01.F EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
54
9.3.4 T
HE
C
LIP
I
NFORMATION
A
REA
The next area is the Clip Information Area which displays the clips of the
selected page and bank(s). Two clips’ banks are displayed at a time.
For each clip and camera angle, the following information is available:
Field Description
Clip ID Unique identifier of the clip on the server. Ex: 111A
The clip ID is followed by the “Creating” message when
the clip is in the process of being created, copied or
moved to this location.
For more information on ‘Record in progress’ clips,
refer to the section 9.2.5 ‘Recall and Playback of
“Record in Progress” Clips’, on page 40.
Clip “rank” Clip rank depending on the channel on which it has
been created :
• Primary (“*” next to the clip ID)
• Secondary (“=” next to the clip ID)
The clip rank information is highlighted in blue if the
clip is protected.
Clip name Name of the clip, either automatically assigned or
defined by the user.
Archive Status
• if the clip ID is blinking green, the clip is flagged
for archiving, but not yet archived
• if the clip ID is permanently highlighted in green,
the archiving of the clip has been completed.
Note
In the standard view (cameras A to D), if camera E and/or F exist
for a particular clip, the D-column for this clip is replaced by the
mention “More Clips” on blue background.
