background image

Issue
10.01.F

EVS Multicam Version 10.01 – Operating Manual

EVS Broadcast Equipment SA – July 2009

158

16.1.4

O

VERVIEW ON THE

O

FFSIDE

L

INE

C

OMMANDS

M

AIN

M

ENU

When you access the offside line menu, this is as follows and the Mark key

is blinking:

TRANSP

OSD

QUIT

SHIFT

SIDE

REDO

UNDO

The following table summarizes the various commands available:

OSD Command

Meaning

SHIFT/TILT (A)

Moves the line horizontally (Shift) or around its pivot
point (tilt)

SIDE (B)

Changes the shaded area from side

REDO (C)

Redoes the last undone action.
You can redo the last 10 undone actions.

UNDO (D)

Undoes the last action.
You can undo the last 10 actions.

TRANSP (SHIFT+B) Allows the user to change the transparency level with

the jog or lever. Press Enter to validate the action.

OSD (SHIFT+C)

Allows the user to hide or display again the
information on the OSD.

QUIT (SHIFT+D)

Exits the offside line mode

S

ECONDARY

M

ENU

Pressing the MENU key opens a secondary menu that allows you to specify
the following offside line settings:

Setting Description

Pause duration

Time (in frames) between the train or clip is paused and
the offside line mark is displayed.

Fade in/out
duration

Duration (in frames) of the fading effect on the IN and
OUT points of the offside sequence.

Preroll duration Preroll (in seconds) before the offside sequence

automatically defined as a cue when the sequence is
saved.
