10.01.F EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
148
Displayed letter Function
C marks CUE OUT point on current clip
S plays back the clip at slow motion speed. The speed of
slow motion is predefined in the PGM Speed item from the
Setup Menu (Page2 – F3)
P plays back the current clip at normal speed
The clip countdown displays the field time. This means that the countdown
matches the slow motion speed.
Note
Selecting C (clear) from the monitor enters the Clear menu and the
DFC menu. DFC menu allows you to select the brush colour from a
YUV colour palette
If working in network mode, painting can be performed on remote clips as
well as on local clips.
14.3 FUNCTION DESCRIPTION
S
TRAIGHT
L
INE
/ B
ROKEN
L
INE
D
RAWING
(L)
Select L on the Paint Mode monitor display. You will then be prompted to
enter the first point of the line.
Place the pen at the start point and press lightly. Then place the pen at the
next point and press lightly again. A straight line appears to connect these 2
points. Repeat this as many times until the line is complete, then place the
pen over the “ESC” area in the top right corner of the OSD and press lightly.
The system automatically defaults back to freehand drawing mode.
C
IRCLE
D
RAWING
(O)
Select this menu to draw circles.
A menu allows you to choose between the following options:
• Set centre (default): A pointer appears on the screen to let you choose
the centre of the circle. The radius will be the one last used or the
default one if none has been defined before.
• Define: This option allows you to change the size of a circle.
Click on the Define menu and follow the instructions:
o Set the centre of the circle
o Set the radius
You can then choose to save or not the new circle:
• Esc: no circle is drawn.
