EVS Multicam Version 10.01 – Operating Manual

EVS Broadcast Equipment SA – July 2009

Issue
10.01.F


127

11.14.6

L

OOP

M

ODE IN THE

R

EPLACE

F

UNCTION

L

OOP

T

YPE

When the IN point has been marked, the display switches to:

Cam A

+2fields

Replace Int.Loop Ext.Loop

The Int. Loop and Ext. Loop keys are blinking.

Before entering the Replace Playback mode, the operator has to choose
between Internal Loop or External Loop.

The Internal Loop is the same loop as the existing loop process.

The External Loop allows you to select on which channel you will physically

re-record the output of your PGM. The link is physical: it is necessary to
make the video link manually with a router or vide/audio cables, it is not
done inside the server.

A

DDITIONAL

L

OOP

P

ARAMETERS

Additional parameters are available for the external loop:
• With the Cam A function (SHIFT+C), you can select the camera the PGM

will be recorded to for the external LOOP process. Press SHIFT+C until
the desired camera is selected.

• With the +2 fields function (SHIFT+D), you can select by how much the

video coming back to your record channel will be delayed. If you are

using a DVE, it could introduce a delay. This system is based on the
assumption that audio and video are in sync when they hit the record
channel. The delay value can not be negative.

Select SHIFT+D to highlight the delay value and the display allows you
to add frames or fields of delay to the delay value. Pressing either MENU
or SHIFT+D will leave this mode.
