EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
7
same picture inside the record train, if it still exists.
PRV CTL Enables/disables the Preview Control mode.
PAGE Selects current clip page, from 1 to 10.
7. LCD Display Provides current status of system
2.2 LED COLOURS
A selected key lights red.
When a key lights green, it means a value in relation with this key exists.
For example: F1 to F0 keys
• Green light means a clip has been stored in relation with the key.
• Green flashing light means a clip is being created.
• Red light means the clip associated to the key is playing or is ready to
play.
• Red flashing light means a clip is being deleted (in network mode)
2.3 F-KEYS & SMALL BUTTONS
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
MENU SHIFT CLEAR ENTER
This button provides access to the Secondary Menu. Also
used as CANCEL in some messages when confirmation is
required.
Note: SHIFT + MENU returns to Main menu
Enables use of the secondary key functions.
Note: This key remains active even if released, until another
key has been hit.
Stores or recalls clips, recall playlists and enter timecode
information.
Is a multi-purpose key used to clear clips or playlists, and to
clear IN/OUT points.
Is used to append clips at the end of the current playlist, and
to validate other options and messages.
MENU
SHIFT
F1 F10
-
CLEAR
ENTER
