15.2 CREATING A TARGET TRACK
Begin by selecting all the appropriate types of tracking object, their size,
colour, etc.
15.2.1 S
ELECTING THE TYPE OF TRACKING OBJECT
The character on the left of the “T” letter on the 1 s t line of the OSD shows
the current object:
O (letter “o”) Indicates a circle (default option)
0 (zero) Indicates a ellipse
↓ / ↑ / → / ← Indicates an arrow
█ Indicates a rectangle
Z Indicates the zoom mode is active (circle only
available in this mode)
15.2.2 S
ELECTING
O
THER
P
ARAMETERS OF THE
T
RACKING
O
BJECT
T: Select the background shade (Transparency level)
E: Select the border thickness (Edge)
S: Select the size of the tracking object (Size)
C: Select the border colour (Colour)
Note
To select the size of the tracking object when it is a rectangle
or an ellipse, click on S on the first line of the OSD. You must
define the position of 2 opposite corners of the rectangle (in case
of an ellipse, you must define the opposite corners of the
rectangle the ellipse in enclosed in). When these 2 corners are
defined, the system draws the resulting rectangle or ellipse. You
can confirm by clicking on OK or clear the screen by clicking on
CLEAR and redefine a new shape.
