10.01.F EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
30
7. Multi PGM Mode
7.1 1/2/3 PGM MODES (PRESS A OR B
FROM MAIN MENU)
Multicam has two modes for its basic operation, 1 PRV/PGM mode or Multi
PGM mode:
• The 1PGM+PRV mode, as described previously, is the more powerful of
the two, allowing for interaction between all outputs. Here, synchronized
replays can be rolled and chained between the cameras with either a
mix, wipe, or cut between them.
• The MULTI PGM mode is more basic, which gives the operator
independent control of all outputs.
In this mode, all outputs can be controlled together (such as jogging back to
a certain action, with all outputs) or they can be controlled individually
(either PGM 1, 2 or 3).
7.1.1 S
ECONDARY
M
ENU
The secondary menu can be called by pressing the MENU key and is similar
to the 1PGM+PRV mode, except that the A function is empty since it is not
possible to create a transition between the channels in this mode. Please
refer to the Chapter 6 ‘PGM-PRV Mode’, on page 24 for description of the
other functions of the secondary menu.
PGM1 CAM A *PGM2* CAM B PGM3 CAM C
Aud.Met. PgmSpd Sort->TC Post-Roll
Sw to IN Search Pref
P.1
B.1 Clips: LOCAL Records: LOCAL
PL 11: <
Msg:
Rst Cam Local Sync To 2nd CTRL
PGM 1 PGM 2 PGM 3 TOGGLE
