4.1.17 GOTO TC
The Goto TC option allows the user to jump to a given timecode in the
loaded train or clip.
H
OW TO
G
O TO A
G
IVEN
T
IMECODE
To jump to a given timecode of the loaded train or clip, you can use the
Goto TC option on the Remote Panel.
To go to a given timecode, proceed as follows:
1. Press SHIFT+GOTO TC key on the Remote.
The GOTO TC window is displayed on the Remote Panel :
Go to TC xx:xx:xx:xx
[Menu] : Cancel
[Enter] : Go to TC
Reset From Date To Date
Return LTC
2. To specify a date from which the search should be executed, press
SHIFT+C, enter the date in the following format dd/mm/yy using the
F1 to F10 keys and press ENTER on the Remote.
3. To specify a date up to which the search should be executed, press
SHIFT+D and enter the date in the following format dd/mm/yy using
the F1 to F10 keys and press ENTER on the Remote.
4. To specify whether to go to a LTC, USER timecode or any of both
(LTC/USER), press C until the requested timecode type is displayed.
5. Enter the requested timecode using the function keys F1 to F10.
Eight digits: hh:mm:ss;ff (f=frame) are displayed on the LCD screen of
the Remote.
• If you enter all 8 digits, Multicam will automatically go to the
required timecode.
• If you enter less than 8 digits (when the last digits are zeros),
press ENTER on the Remote to validate the entry and reach the
requested timecode.
Once you have entered the Goto TC, you can observe it has been
correctly entered on the display of the Remote LCD screen and on the
output monitor. This Timecode display appears in the centre of the
LCD display, just above the menu options.
6. Press ENTER on the Remote.
If the timecode is from the LTC table, it will be displayed in white on the
output monitor.
If the timecode is from the USER TC table, it will be displayed in yellow
output monitor.
