EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
157
16. Offside Line Mode
16.1 INTRODUCTION
16.1.1 D
EFINITION AND
L
ICENCE
C
ODE
Note
The offside line mode is a software option, which requires the
licence code 114 being installed. For more information on the
required licence key, contact the Support or Sales team.
The Offside Line mode makes it possible to make the offside line visible on
the screen by shading a portion the pitch. You can use this feature on clips
or trains loaded on the PGM1. This effect can then be recorded in the loop
of the server and reinserted in the feed of a recorder channel.
16.1.2 A
CTIVATING THE
O
FFSIDE
L
INE
M
ODE
To activate the offside line mode, you need to set to ‘Yes’ the Offside Line
setting on page 9.2 of the Setup menu on the Remote Panel.
When you activate the offside line, you can no longer use a second
controller.
16.1.3 A
CCESSING THE
O
FFSIDE
L
INE
M
ODE
When the offside line mode is active, the Offside Line option is available
from the operational menu in the PGM/PRV or Multi PGM mode:
Rst Cam Local Sync Prv OFFSIDE
Cam A Cam B
You access this mode by pressing the SHIFT+D key.
