17.1.3 S
PLIT
MIX
This mode works similar to the H and V Split modes, except that there is no
position adjustment since both pictures are shown full frame.
The D key allows the operator to adjust the mix percentage between the two
sources. Press the D key to highlight the function, then move the lever to
adjust the mix level between the two sources.
17.1.4 A
UTO
-
TRACKING MODE
The Auto-tracking mode applies only to the Vertical Split mode, and allows
to adjust the horizontal position of a sequence to make sure it is as close as
possible to the centre of the left/right part of the screen.
To use the Auto-tracking, the first step is to track the object that must be
kept in the centre of the frame. Using the Target Track mode the keyframes
are marked to determine the path of the object. Refer to the Chapter 15
‘Target Mode’, on page 151 for more details.
When the tracking is completed in the desired clips, enter the Split Screen
mode and recall these clips on the left and right side of the screen. If
keyframes have been marked inside selected clips, the word “TRACKED” will
appear on the corresponding side of the output monitor. At playback, the
picture will be shifted horizontally to keep the tracked object in the centre of
its frame.
To disable temporarily the auto-tracking without leaving the Split Screen
mode, press CLEAR+LEFT (disable Auto-tracking on left side) or
CLEAR+RIGHT (disable Auto-tracking on right side).
PGM1 CAM A *PGM2* CAM B
Aud.Met. PgmSpd Sort->TC PostRoll
Sw to IN Search Pref
P.1 B.1 Clips: LOCAL Records: LOCAL
PL 11: <
Msg:
SplitMix Swap Sync
Left Right L & R 050-050%
