ZyWALL 5/35/70 Series User’s Guide
85 Chapter 3 Wizard Setup
Figure 15 ISP Parameters : Ethernet Encapsulation
The following table describes the labels in this screen.
Table 11 ISP Parameters : Ethernet Encapsulation
LABEL DESCRIPTION
ISP Parameters
for Internet
Access
Encapsulation You must choose the Ethernet option when the WAN port is used as a regular
Ethernet. Otherwise, choose PPPoE or PPTP for a dial-up connection.
WAN IP Address
Assignment
IP Address
Assignment
Select Dynamic If your ISP did not assign you a fixed IP address. This is the
default selection.
Select Static If the ISP assigned a fixed IP address.
The fields below are available only when you select Static.
My WAN IP
Address
Enter your WAN IP address in this field.
My WAN IP
Subnet Mask
Enter the IP subnet mask in this field.
Gateway IP
Address
Enter the gateway IP address in this field.
First DNS Server
Second DNS
Server
Enter the DNS server's IP address(es) in the field(s) to the right.
Leave the field as 0.0.0.0 if you do not want to configure DNS servers. If you do not
configure a DNS server, you must know the IP address of a machine in order to
access it.
Apply Click Apply to save your changes and go to the next screen.
