ZyWALL 5/35/70 Series User’s Guide
Chapter 5 LAN Screens 116
5.7 LAN IP Alias
IP alias allows you to partition a physical network into different logical networks over the
same Ethernet interface. The ZyWALL supports three logical LAN interfaces via its single
physical Ethernet interface with the ZyWALL itself as the gateway for each LAN network.
When you use IP alias, you can also configure firewall rules to control access between the
LAN's logical networks (subnets).
Note: Make sure that the subnets of the logical networks do not overlap.
The following figure shows a LAN divided into subnets A, B, and C.
Figure 37 Physical Network & Partitioned Logical Networks
To change your ZyWALL’s IP alias settings, click NETWORK, LAN and then the IP Alias
tab. The screen appears as shown.
IP Address Type the IP address that you want to assign to the computer on your LAN.
Alternatively, click the right mouse button to copy and/or paste the IP address.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 23 LAN Static DHCP
LABEL DESCRIPTION
