ZyWALL 5/35/70 Series User’s Guide
Chapter 19 VPN Screens 316
19.10 VPN Rules (IKE)
Click VPN to display the VPN Rules (IKE) screen. This is a read-only menu of your IPSec
rule (tunnel). To add an IPSec rule (or gateway policy), click the add gateway policy (
)
icon. Edit an IPSec rule by clicking the edit ( ) icon to configure the associated submenus.
Refer to Table 100 on page 317 for descriptions of the icons used in this screen.
Figure 148 VPN Rules (IKE)
The following table introduces some of the general IPSec terms used in the VPN screens.
Table 99 IPSec Fields Summary
LABEL DESCRIPTION
VPN Tunnel A VPN (Virtual Private Network) tunnel gives you a secure connection to another
computer or network.
Gateway Policy A gateway policy identifies the IPSec routers at either end of a VPN tunnel and
specifies the authentication, encryption and other settings needed to negotiate a
phase 1 IKE SA.
Network Policy A network policy identifies the devices behind the IPSec routers at either end of a
VPN tunnel and specifies the authentication, encryption and other settings
needed to negotiate a phase 2 IPSec SA.
My ZyWALL This is the WAN IP address or the domain name of your ZyWALL in router mode
or the ZyWALL’s IP address in bridge mode.
Local Network This is the network behind the ZyWALL.
Remote Gateway
Address
This is the WAN IP address or domain name of the IPSec router with which you're
making the VPN connection.
Remote Network This is the remote network behind the remote IPsec router.
