ZyWALL 5/35/70 Series User’s Guide
Chapter 6 Bridge Screens 128
After you change the LAN/DMZ/WLAN port roles and click Apply, please wait for few
seconds until the following screen appears. Click Return to go back to the Port Roles screen.
Figure 46 Port Roles Change Complete
WLAN When you have the wireless card set to WLAN, you can select a port’s WLAN
radio button to use the port as part of the WLAN.
The port will use the ZyWALL’s WLAN IP address and the MAC address of the
WLAN card.
Note: You must install a wireless card to use the WLAN port role.
See Appendix A on page 664 for how to install a WLAN card.
Wireless Card Select LAN to use the wireless card as part of the LAN.
Select DMZ to use the wireless card as part of the DMZ.
Select WLAN to use the wireless card as part of the WLAN.
The ZyWALL restarts after you change the wireless card setting.
Note: If you set the wireless card to be part of the LAN or DMZ, you
can still use wireless access, but not the WLAN interface in
the firewall. The firewall will treat the wireless card as part of
the LAN or DMZ respectively.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 29 Bridge Port Roles (continued)
LABEL DESCRIPTION
