ZyWALL 5/35/70 Series User’s Guide
Chapter 9 Wireless LAN 192
9.16.1 Static WEP
Static WEP provides a mechanism for encrypting data using encryption keys. Both the AP and
the wireless stations must use the same WEP key to encrypt and decrypt data. Your ZyWALL
allows you to configure up to four 64-bit or 128-bit WEP keys, but only one key can be used at
any one time.
In order to configure and enable WEP encryption, click the NETWORK and WIRELESS
CARD to display the Wireless Card screen. Select Static WEP from the Security list.
Fragmentation
Threshold
This is the threshold (number of bytes) for the fragmentation boundary for directed
messages. It is the maximum data fragment size that can be sent.
Select the check box to change the default value and enter a value between 256 and
2432.
Security Choose from one of the security settings listed in the drop-down box.
•
No Security
• Static WEP
• WPA-PSK
• WPA
• 802.1x + Dynamic WEP
• 802.1x + Static WEP
• 802.1x + No WEP
• No Access 802.1x + Static WEP
• No Access 802.1x + No WEP
Select No Security to allow wireless stations to communicate with the access points
without any data encryption. Otherwise, select the security you need and see the
following sections for more information.
Note: The installed ZyXEL WLAN card may not support all of the
WLAN security features you can configure in the ZyWALL.
Please see the product specifications appendix for a table of
compatible ZyXEL WLAN cards and the WLAN security features
each card supports.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 54 Wireless Card: No Security (continued)
LABEL DESCRIPTION
