ZyWALL 5/35/70 Series User’s Guide
Chapter 9 Wireless LAN 180
9.5 WLAN Port Roles
Use the Port Roles screen to set ports as LAN, DMZ or WLAN interfaces. The LAN port role
is not available on all models.
Connect wireless LAN Access Points (APs) to WLAN interfaces to extend the ZyWALL’s
wireless LAN coverage. The WLAN port role allows the ZyWALL’s firewall to treat traffic
from connected APs as part of the ZyWALL’s WLAN. You can specify firewall rules for
traffic going to or from the WLAN. The WLAN includes the ZyWALL’s own WLAN and the
Ethernet ports in the WLAN port role.
The following figure shows the ZyWALL with a wireless card installed and an AP connected
to an Ethernet port in the WLAN port role.
Figure 73 WLAN Port Role Example
RIP Version The RIP Version field controls the format and the broadcasting method of the RIP
packets that the ZyWALL sends (it recognizes both formats when receiving). RIP-1
is universally supported but RIP-2 carries more information. RIP-1 is probably
adequate for most networks, unless you have an unusual network topology. Both
RIP-2B and RIP-2M sends the routing data in RIP-2 format; the difference being
that RIP-2B uses subnet broadcasting while RIP-2M uses multicasting.
Multicasting can reduce the load on non-router machines since they generally do
not listen to the RIP multicast address and so will not receive the RIP packets.
However, if one router uses multicasting, then all routers on your network must use
multicasting, also. By default, RIP direction is set to Both and the Version set to
RIP-1.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 51 WLAN IP Alias
LABEL DESCRIPTION
