ZyWALL 5/35/70 Series User’s Guide
Chapter 8 DMZ Screens
164
RIP Version
The RIP Version field controls the format and the broadcasting method of the RIP
packets that the ZyWALL sends (it recognizes both formats when receiving). RIP-
1 is universally supported but RIP-2 carries more information. RIP-1 is probably
adequate for most networks, unless you have an unusual network topology. Both
RIP-2B and RIP-2M sends the routing data in RIP-2 format; the difference being
that RIP-2B uses subnet broadcasting while RIP-2M uses multicasting.
Multicasting can reduce the load on non-router machines since they generally do
not listen to the RIP multicast address and so will not receive the RIP packets.
However, if one router uses multicasting, then all routers on your network must
use multicasting, also. By default, RIP direction is set to Both and the Version set
to RIP-1.
Multicast
Select IGMP V-1 or IGMP V-2 or None. IGMP (Internet Group Multicast Protocol)
is a network-layer protocol used to establish membership in a Multicast group - it
is not used to carry user data. IGMP version 2 (RFC 2236) is an improvement
over version 1 (RFC 1112) but IGMP version 1 is still in wide use. If you would like
to read more detailed information about interoperability between IGMP version 2
and version 1, please see sections 4 and 5 of RFC 2236.
DHCP Setup
DHCP
DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows
individual clients (workstations) to obtain TCP/IP configuration at startup from a
server. Unless you are instructed by your ISP, leave this field set to Server. When
configured as a server, the ZyWALL provides TCP/IP configuration for the clients.
When set as a server, fill in the IP Pool Starting Address and Pool Size fields.
Select Relay to have the ZyWALL forward DHCP requests to another DHCP
server. When set to Relay, fill in the DHCP Server Address field.
Select None to stop the ZyWALL from acting as a DHCP server. When you select
None, you must have another DHCP server on your LAN, or else the computers
must be manually configured.
IP Pool Starting
Address
This field specifies the first of the contiguous addresses in the IP address pool.
Pool Size
This field specifies the size, or count of the IP address pool.
DHCP Server
Address
Type the IP address of the DHCP server to which you want the ZyWALL to relay
DHCP requests. Use dotted decimal notation. Alternatively, click the right mouse
button to copy and/or paste the IP address.
Windows
Networking
(NetBIOS over
TCP/IP)
Allow between DMZ
and LAN
Select this check box to forward NetBIOS packets from the LAN to the DMZ and
from the DMZ to the LAN. If your firewall is enabled with the default policy set to
block DMZ to LAN traffic, you also need to enable the default DMZ to LAN firewall
rule that forwards NetBIOS traffic.
Clear this check box to block all NetBIOS packets going from the LAN to the DMZ
and from the DMZ to the LAN.
Allow between DMZ
and WAN
Select this check box to forward NetBIOS packets from the WAN to the DMZ and
from the DMZ to the WAN.
Clear this check box to block all NetBIOS packets going from the WAN to the
DMZ and from the DMZ to the WAN.
Table 45 DMZ (continued)
LABEL
DESCRIPTION
