ZyWALL 5/35/70 Series User’s Guide

601

Chapter 46 System Information & Diagnosis

3 There are three commands in Menu 24.1 - System Maintenance - Status. Entering 1

drops the WAN connection, 9 resets the counters and [ESC] takes you back to the
previous screen.

Figure 356 Menu 24.1: System Maintenance: Status

The following table describes the fields present in Menu 24.1 - System Maintenance -
Status
. These fields are READ-ONLY and meant for diagnostic purposes. The upper right
corner of the screen shows the time and date according to the format you set in menu 24.10.


Menu 24.1 - System Maintenance - Status 08:17:55
Wed. Jul. 27, 2005
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
WAN1 100M/Full 9439 332111 0 0 1062 2:35:42
WAN2 Down 0 0 0 0 0 0:00:00
LAN 100M/Full 7802 11353 0 354 192 2:35:42
WCRD Down 0 0 0 0 0 0:00:00
DMZ 100M/Full 0 0 0 0 0 2:35:42
WLAN 100M/Full 0 0 0 0 0 2:35:42

Port Ethernet Address IP Address IP Mask DHCP
WAN1 00:A0:C5:01:23:46 172.22.1.162 255.255.0.0 Client
WAN2 00:A0:C5:01:23:48 0.0.0.0 0.0.0.0 Client
LAN 00:A0:C5:01:23:45 192.168.1.1 255.255.255.0 Server
WLAN 00:00:00:00:00:00
DMZ 00:A0:C5:01:23:47 10.10.2.1 255.255.255.0 None

System up Time: 2:35:47
CARD bridged to: LAN
Press Command:

COMMANDS: 1, 2-Drop WAN1,2 9-Reset Counters ESC-Exit

Table 226 System Maintenance: Status Menu Fields

FIELD

DESCRIPTION

Port

This field identifies a port (WAN, LAN, WCRD (wireless LAN card), DMZ or WLAN)

on the ZyWALL.

Status

For the LAN, DMZ, and WLAN Interfaces, this displays the port speed and duplex

setting.
For the WAN port, it displays the port speed and duplex setting if you’re using

Ethernet encapsulation and Down (line is down or not connected), Idle (line (ppp)

idle), Dial (starting to trigger a call) or Drop (dropping a call) if you’re using PPPoE

encapsulation.
For the wireless card, it displays the transmission rate when a wireless LAN card is

inserted and WLAN is enabled or Down when a wireless LAN is not inserted or

WLAN is disabled.

TxPkts

This is the number of transmitted packets on this port.

RxPkts

This is the number of received packets on this port.

Cols

This is the number of collisions on this port.

Tx B/s

This field shows the transmission speed in Bytes per second on this port.
