ZyWALL 5/35/70 Series User’s Guide
Chapter 47 Firmware and Configuration File Maintenance
620
47.4.2 Restore Using FTP Session Example
Figure 373 Restore Using FTP Session Example
to read about configurations that disallow TFTP and FTP
over WAN.
47.4.3 Restore Via Console Port
Restore configuration via console port by following the HyperTerminal procedure shown next.
Procedures using other serial communications programs should be similar.
1 Display menu 24.6 and enter “y” at the following screen.
Figure 374 System Maintenance: Restore Configuration
2 The following screen indicates that the Xmodem download has started.
Figure 375 System Maintenance: Starting Xmodem Download Screen
3 Run the HyperTerminal program by clicking Transfer, then Send File as shown in the
following screen.
Figure 376 Restore Configuration Example
ftp> put config.rom rom-0
200 Port command okay
150 Opening data connection for STOR rom-0
226 File received OK
221 Goodbye for writing flash
ftp: 16384 bytes sent in 0.06Seconds 273.07Kbytes/sec.
ftp>quit
Ready to restore Configuration via Xmodem.
Do you want to continue (y/n):
Starting XMODEM download (CRC mode) ...CCCCCCCCC
Type the configuration file’s location,
or click Browse to search for it.
Choose the Xmodem protocol.
Then click Send.
