ZyWALL 5/35/70 Series User’s Guide
565 Chapter 42 Network Address Translation (NAT)
42.2.1 Address Mapping Sets
Enter 1 to bring up Menu 15.1 - Address Mapping Sets.
Figure 316 Menu 15.1: Address Mapping Sets
42.2.1.1 SUA Address Mapping Set
Enter 255 to display the next screen (see also Section 42.1.1 on page 562 ). The fields in this
menu cannot be changed.
Figure 317 Menu 15.1.255: SUA Address Mapping Rules
The following table explains the fields in this menu.
Menu 15.1 - Address Mapping Sets
1. NAT_SET
2. example
255. SUA (read only)
Enter Menu Selection Number:
Menu 15.1.1 - Address Mapping Rules
Set Name= SUA
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ---
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server
3.
4.
5.
6.
7.
8.
9.
10.
Press ENTER to Confirm or ESC to Cancel:
