ZyWALL 5/35/70 Series User’s Guide
197 Chapter 9 Wireless LAN
9.16.5 IEEE 802.1x + Static WEP
Click the NETWORK and WIRELESS CARD to display the Wireless Card screen. Select
802.1x + Static WEP from the Security list.
Figure 85 Wireless Card: 802.1x + Static WEP
The following wireless LAN security fields become available when you select 802.1x + Static
WEP in the Security drop down list-box.
Table 59 Wireless Card: 802.1x + Static WEP
LABEL DESCRIPTION
Security Select 802.1x + Static WEP from the drop-down list.
WEP Encryption WEP (Wired Equivalent Privacy) provides data encryption to prevent unauthorized
wireless stations from accessing data transmitted over the wireless network.
Select 64-bit WEP or 128-bit WEP to enable data encryption.
Key 1 to Key 4 If you chose 64-bit WEP in the WEP Encryption field, then enter any 5 characters
(ASCII string) or 10 hexadecimal characters ("0-9", "A-F") preceded by 0x for each
key.
If you chose 128-bit WEP in the WEP Encryption field, then enter 13 characters
(ASCII string) or 26 hexadecimal characters ("0-9", "A-F") preceded by 0x for each
key.
There are four data encryption keys to secure your data from eavesdropping by
unauthorized wireless users. The values for the keys must be set up exactly the
same on the access points as they are on the wireless stations.
