50.2.1 Applying Policy to Packets
To apply the policy to packets received on the selected interface(s), go to Menu 25.1: IP
Routing Policy Setup and press [SPACE BAR] to select Yes in the Edit policy to packets
received from field. Press [ENTER] to display Menu 25.1.1 - IP Routing Policy Setup
(shown next).
port start / end Source port number range from start to end; applicable only for TCP/UDP.
Destination
addr start / end Destination IP address range from start to end.
port start / end Destination port number range from start to end; applicable only for TCP/UDP.
Action Specifies whether action should be taken on criteria Matched or Not Matched.
Gateway Type Press [SPACE BAR] and then [ENTER] to select IP Address and enter the IP
address of the gateway if you want to specify the IP address of the gateway. The
gateway is an immediate neighbor of your ZyWALL that will forward the packet to
the destination. The gateway must be a router on the same segment as your
ZyWALL's LAN or WAN port.
Press [SPACE BAR] and then [ENTER] to select Remote Node to have the
ZyWALL send traffic that matches the policy route through a specific WAN port.
Gateway addr This field displays if you selected IP Address in the Gateway Type field. Defines
the outgoing gateway address. The gateway must be on the same subnet as the
ZYWALL if it is on the LAN, otherwise, the gateway must be the IP address of a
remote node. The default gateway is specified as 0.0.0.0.
Remote Node Idx This field displays if you selected Remote Node in the Gateway Type field. Type 1
for WAN port 1 or 2 for WAN port 2.
Redirect Packet This field applies if you selected Remote Node in the Gateway Type field.
Press [SPACE BAR] and then [ENTER] to select Yes to have the ZyWALL send
traffic that matches the policy route through the other WAN interface if it cannot
send the traffic through the WAN interface you selected.
Type of Service Set the new TOS value of the outgoing packet. Prioritize incoming network traffic
by choosing Don't Care, Normal, Min Delay, Max Thruput, Max Reliable or Min
Cost.
Precedence Set the new outgoing packet precedence value. Values are 0 to 7 or Don't Care.
Log Press [SPACE BAR] and then [ENTER] to select Yes to make an entry in the
system log when a policy is executed.
Edit policy to
packets received
from
Press [SPACE BAR] and then [ENTER] to select Yes or No (default). Select Yes
to configure Menu 25.1.1: IP Routing Policy Setup discussed next.
When you have completed this menu, press [ENTER] at the prompt "Press [ENTER] to confirm or
[ESC] to cancel" to save your configuration or press [ESC] to cancel and go back to the previous
screen.
Table 240 Menu 25.1: IP Routing Policy Setup
FIELD DESCRIPTION
