ZyWALL 5/35/70 Series User’s Guide
151 Chapter 7 WAN Screens
The following table describes the labels in this screen.
Table 41 WAN: PPTP Encapsulation
LABEL DESCRIPTION
ISP Parameters for
Internet Access
Encapsulation Point-to-Point Tunneling Protocol (PPTP) is a network protocol that enables
secure transfer of data from a remote client to a private server, creating a Virtual
Private Network (VPN) using TCP/IP-based networks. PPTP supports on-
demand, multi-protocol, and virtual private networking over public networks, such
as the Internet. The ZyWALL supports only one PPTP server connection at any
given time. To configure a PPTP client, you must configure the User Name and
Password fields for a PPP connection and the PPTP parameters for a PPTP
connection.
User Name Type the user name given to you by your ISP.
Password Type the password associated with the user name above.
Retype to Confirm Type your password again to make sure that you have entered is correctly.
Authentication
Type
Use the drop-down list box to select an authentication protocol for outgoing calls.
Options are:
CHAP/PAP - Your ZyWALL accepts either CHAP or PAP when requested by this
remote node.
CHAP - Your ZyWALL accepts CHAP only.
PAP - Your ZyWALL accepts PAP only.
Nailed-up Select Nailed-Up if you do not want the connection to time out.
Idle Timeout This value specifies the time in seconds that elapses before the ZyWALL
automatically disconnects from the PPTP server.
PPTP
Configuration
My IP Address Type the (static) IP address assigned to you by your ISP.
My IP Subnet Mask Your ZyWALL will automatically calculate the subnet mask based on the IP
address that you assign. Unless you are implementing subnetting, use the subnet
mask computed by the ZyWALL.
Server IP Address Type the IP address of the PPTP server.
Connection ID/
Name
Type your identification name for the PPTP server.
WAN IP Address
Assignment
Get automatically
from ISP
Select this option If your ISP did not assign you a fixed IP address. This is the
default selection.
Use Fixed IP
Address
Select this option If the ISP assigned a fixed IP address.
My WAN IP
Address
Enter your WAN IP address in this field if you selected Use Fixed IP Address.
Advanced Setup
