ZyWALL 5/35/70 Series User’s Guide
163 Chapter 8 DMZ Screens
Figure 63 DMZ
The following table describes the labels in this screen.
Table 45 DMZ
LABEL DESCRIPTION
DMZ TCP/IP
IP Address Type the IP address of your ZyWALL’s DMZ port in dotted decimal notation.
Note: Make sure the IP addresses of the LAN, WAN, WLAN and
DMZ are on separate subnets.
IP Subnet Mask The subnet mask specifies the network number portion of an IP address. Your
ZyWALL will automatically calculate the subnet mask based on the IP address
that you assign. Unless you are implementing subnetting, use the subnet mask
computed by the ZyWALL 255.255.255.0.
RIP Direction RIP (Routing Information Protocol, RFC1058 and RFC 1389) allows a router to
exchange routing information with other routers. The RIP Direction field controls
the sending and receiving of RIP packets. Select the RIP direction from Both/In
Only/Out Only/None. When set to Both or Out Only, the ZyWALL will broadcast
its routing table periodically. When set to Both or In Only, it will incorporate the
RIP information that it receives; when set to None, it will not send any RIP
packets and will ignore any RIP packets received. Both is the default.
