ZyWALL 5/35/70 Series User’s Guide
Chapter 1 Getting to Know Your ZyWALL 64
The following table describes the LEDs.
Table 2 Front Panel LEDs
LED COLOR STATUS DESCRIPTION
PWR Off The ZyWALL is turned off.
Green On The ZyWALL is turned on.
Red On The power to the ZyWALL is too low.
SYS Green Off The ZyWALL is not ready or has failed.
On The ZyWALL is ready and running.
Flashing The ZyWALL is restarting.
ACT Green Off The backup port is not connected.
Flashing The backup port is sending or receiving packets.
CARD Green Off The wireless LAN is not ready, or has failed.
On The wireless LAN is ready.
Flashing The wireless LAN is sending or receiving packets.
LAN 10/100
(ZyWALL 70
only)
Off The LAN/DMZ is not connected.
Green On The ZyWALL has a successful 10Mbps Ethernet connection.
Flashing The 10M LAN is sending or receiving packets.
Orange On The ZyWALL has a successful 100Mbps Ethernet
connection.
Flashing The 100M LAN is sending or receiving packets.
WAN1/2 10/100
or
WAN 10/100 Off The WAN connection is not ready, or has failed.
Green On The ZyWALL has a successful 10Mbps WAN connection.
Flashing The 10M WAN is sending or receiving packets.
Orange On The ZyWALL has a successful 100Mbps WAN connection.
Flashing The 100M WAN is sending or receiving packets.
DMZ 10/100
(ZyWALL 70
only)
Off The LAN/DMZ is not connected.
Green On The ZyWALL has a successful 10Mbps Ethernet connection.
Flashing The 10M LAN is sending or receiving packets.
Orange On The ZyWALL has a successful 100Mbps Ethernet
connection.
Flashing The 100M LAN is sending or receiving packets.
LAN/DMZ 10/
100
(ZyWALL 35
and ZyWALL 5)
Off The LAN/DMZ is not connected.
Green On The ZyWALL has a successful 10Mbps Ethernet connection.
Flashing The 10M LAN is sending or receiving packets.
Orange On The ZyWALL has a successful 100Mbps Ethernet
connection.
Flashing The 100M LAN is sending or receiving packets.
