ZyWALL 5/35/70 Series User’s Guide
127 Chapter 6 Bridge Screens
Figure 44 WLAN Port Role Example
To change your ZyWALL’s port role settings, click NETWORK, BRIDGE and then the Port
Roles tab. The screen appears as shown.
The radio buttons on the left correspond to Ethernet ports on the front panel of the ZyWALL.
Ports 1 to 4 are all DMZ ports on the ZyWALL 70 and all LAN ports on the ZyWALL 5 or
ZyWALL 35 by default. The radio buttons on the right are for the WLAN card.
Figure 45 Bridge Port Roles
The following table describes the labels in this screen.
Table 29 Bridge Port Roles
LABEL DESCRIPTION
LAN Select a port’s LAN radio button to use the port as part of the LAN. The port will
use the LAN IP address and MAC address.
DMZ Select a port’s DMZ radio button to use the port as part of the DMZ. The port will
use the DMZ IP address and MAC address.
