ZyWALL 5/35/70 Series User’s Guide
551
Chapter 40 Remote Node Setup
Figure 303 Menu 11: Remote Node Setup
40.3 Remote Node Profile Setup
The following explains how to configure the remote node profile menu. Not all fields are
available on all models.
40.3.1 Ethernet Encapsulation
There are three variations of menu 11.x depending on whether you choose Ethernet
Encapsulation, PPPoE Encapsulation or PPTP Encapsulation. You must choose the
Ethernet option when the WAN port is used as a regular Ethernet. The first menu 11.x screen
you see is for Ethernet encapsulation shown next.
Figure 304 Menu 11.1: Remote Node Profile for Ethernet Encapsulation
Menu 11 - Remote Node Setup
1. WAN_1 (ISP, SUA)
2. WAN_2 (ISP, NAT)
3. -Dial (BACKUP_ISP, SUA)
Enter Node # to Edit:
Menu 11.1 - Remote Node Profile
Rem Node Name= WAN_1 Route= IP
Active= Yes
Encapsulation= Ethernet Edit IP= No
Service Type= Standard Session Options:
Schedules=
Outgoing: Edit Filter Sets= No
My Login= N/A
My Password= N/A
Retype to Confirm= N/A
Server= N/A
Relogin Every (min)= N/A
Press ENTER to Confirm or ESC to Cancel:
