ZyXEL Communications 70 Series - Manual (Page 178)

ZyWALL 5/35/70 Series User’s Guide
Chapter 9 Wireless LAN 178
Figure 71 WLAN Static DHCP
The following table describes the labels in this screen.
9.4 WLAN IP Alias
IP alias allows you to partition a physical network into different logical networks over the
same Ethernet interface. The ZyWALL supports three logical WLAN interfaces via its single
physical Ethernet interface with the ZyWALL itself as the gateway for each WLAN network.
Table 50 WLAN Static DHCP
LABEL DESCRIPTION
# This is the index number of the Static IP table entry (row).
MAC Address Type the MAC address of a computer on your WLAN.
IP Address Type the IP address that you want to assign to the computer on your WLAN.
Alternatively, click the right mouse button to copy and/or paste the IP address.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
