Hardware Reference Manual 423
Intel
®
IXP2800 Network Processor
Performance Monitor Unit
11.4.6.28 DRAM DPLA Events Target ID(010010) / Design Block #(0011)
33 FIFO Full – Queue Cmd Q P_CLK long separate FIFO Full – Queue Cmd Q
34 FIFO Dequeue – Rd Cmd Q S_CLK single separate FIFO Dequeue – Rd Cmd Q
35 FIFO Enqueue – Rd Cmd Q P_CLK single separate FIFO Enqueue – Rd Cmd Q
36 FIFO Valid – Rd Cmd Q S_CLK long separate FIFO Valid – Rd Cmd Q
37 FIFO Full – Rd Cmd Q P_CLK long separate FIFO Full – Rd Cmd Q
38 FIFO Dequeue – Oref Cmd Q S_CLK single separate FIFO Dequeue – Oref Cmd Q
39 FIFO Enqueue – Oref Cmd Q P_CLK single separate FIFO Enqueue – Oref Cmd Q
40 FIFO Valid – Oref Cmd Q S_CLK long separate FIFO Valid – Oref Cmd Q
41 FIFO Full – Oref Cmd Q P_CLK long separate FIFO Full – Oref Cmd Q
42 FIFO Dequeue – SP0 Pull Data Q S_CLK single separate FIFO Dequeue – SP0 Pull Data Q
43 FIFO Enqueue – SP0 Pull Data Q P_CLK single separate FIFO Enqueue – SP0 Pull Data Q
44 FIFO Valid – SP0 Pull Data Q S_CLK long separate FIFO Valid – SP0 Pull Data Q
45 FIFO Full – SP0 Pull Data Q P_CLK long separate FIFO Full – SP0 Pull Data Q
46 FIFO Dequeue – SP1 Pull Data Q S_CLK single separate FIFO Dequeue – SP1 Pull Data Q
47 FIFO Enqueue – SP1 Pull Data Q P_CLK single separate FIFO Enqueue – SP1 Pull Data Q
48 FIFO Valid – SP1 Pull Data Q S_CLK long separate FIFO Valid – SP1 Pull Data Q
49 FIFO Full – SP1 Pull Data Q P_CLK long separate FIFO Full – SP1 Pull Data Q
50 FIFO Dequeue – Push ID/Data Q P_CLK single separate FIFO Dequeue – Push ID/Data Q
51 FIFO Enqueue – Push ID/Data Q S_CLK single separate FIFO Enqueue – Push ID/Data Q
52 FIFO Valid – Push ID/Data Q P_CLK long separate FIFO Valid – Push ID/Data Q
53 FIFO Full – Push ID/Data Q S_CLK long separate FIFO Full – Push ID/Data Q
Table 181. SRAM CH0 PMU Event List (Sheet 2 of 2)
Table 182. IXP2800 Network Processor Dram DPLA PMU Event List (Sheet 1 of 2)
Event
Number
Event Name
Clock
Domain
Single
pulse/
Long
pulse
Burst Description
0 d0_enq_id_wph P_CLK single separate Enqueue d0 cmd
1 d0_deq_id_wph P_CLK single separate Dequeue d0 cmd
2 dram_req_rph[0] P_CLK single separate d0 has a valid req
3 next_d0_full_wph P_CLK single separate d0 FIFO hit the full threshold
4 d1_enq_id_wph P_CLK single separate Enqueue d1 cmd
5 d1_deq_id_wph P_CLK single separate Dequeue d1 cmd
6 dram_req_rph[1] P_CLK single separate d1 has a valid req
7 next_d1_full_wph P_CLK single separate d1 FIFO hit the full threshold
8 d2_enq_id_wph P_CLK single separate Enqueue d2 cmd
